Balto® Ligatek – Adjustable Hinged Knee Brace

The meticulously crafted Balto® Ligatek stabilizes the knee joint deficiency of your dog, whether it is acquired or post-traumatic. The user can regulate the ROM (range of motion) and secure the joint into complete immobilization or predetermined degrees of flexion and extension through the use of its adjustable hinges. This facilitates the adaptable resolution of a diverse range of requirements. Our trimmable straps allow for adjustments to be made to the girth and length of the brace. Additionally, the padding on the upper and lower sides can be shortened or lengthened to provide a customized fit around the leg.

BRACE APPLICATIONS

• Post-surgical support (for surgeries such as TPLO, TTA, ELSS, and MPL)
• Structural support to injured or affected limbs
• ROM regulation for specific rehabilitation plans
• Acute knee pain or discomfort
• Conservative treatment; use as an alternative to surgery for ineligible surgical candidates.

BRACE FEATURES

• Four lightweight airplane aluminum splints for support around knee joint
• An adjustable external hinge with secure lock technology for a custom range of motion (ROM) setting
• Range of motion can be set to a variety of degrees:
  • Full Joint Immobilization (typically used pre/post-surgically) = 30° Flexion Position (FLEX) / 30° extension position (EXT)
  • Reduced Range of Motion (ROM) (typically used during rehabilitation) = 75° Flexion Position (FLEX) / 30° extension position (EXT)
• Adjustable upper and lower padding straps can be lengthened or shortened on the leg to ensure an excellent fit

Comes in sizes small through x-large, for left and right orientation. To find the best size for your pet, visit the sizing chart here

Non-neoprene braces from Balto® are constructed from superior materials; neoprene is notorious for harboring pathogens, offering insufficient support, and deteriorating rapidly. A range of dimensions guarantees a snug fit. A no-pinch product. Recommended for all ages, unless veterinarians advise otherwise. When applicable, apply the brace in proportionate increments of time for animals under the age of two to avoid potential growth disruptions.

Compare Like Braces

	Balto Jump	Bilateral Balto Jump	Balto Ligatek
Uses	Used to stabilize the knee and provide compression.	Used to stabilize the knee and provide compression bilaterally.	Used to control the range of motion (ROM) and stabilize the knee.
Splints	The aluminum (slightly adjustable) splints are removable.	The aluminum (slightly adjustable) splints are removable bilaterally.	The aluminum splints are not removable, but are adjustable.
Fit	Uses adjustable Velcro for a secure fit and comes with a male and female anchor kit.	Uses adjustable Velcro for a secure fit while the braces anchor together across the back.	Uses adjustable hinges and padding for a secure fit and comes with a kit for setting the range of motion (ROM).

Size Chart

Instructions for Use

Step 1

Prepare the brace by opening the straps. Place the brace on the leg and position the brace by lining up the central hinge with the knee (patella). The dog needs to be standing with their weight catered (Fig. 1).

Step 2

Adjusting the lower padding (if needed): Use the biggest tool to loosen the two screws. Adjust the height of the padding by sliding it on the guide rail and then tightening the screws (Fig. 2).

Step 3

The lower padding is in the appropriate position when it rests above the knee (patella) without obstructing the joint (Fig. 3).

Step 4

Adjusting the upper padding (if needed): follow the same procedure used for the lower padding (Fig. 4).

Step 5

Adjusting the hinges: Use the smaller tool to adjust the hinges (Fig. 5).

Step 6

Secure all the Velcro straps (starting with the bottom strap) around the leg by passing them through the buckles. Tightly close with the Velcro straps (Fig. 6).

Step 7

Secure the strap over the knee (patella) by moving it slightly upward. The strap over the knee stabilizes the two central hinges during flexion (Fig. 7).

ANCHOR KIT

Step 1

Pass the back strap over the dog’s back, open up the anchor kit, and close it around the top of the contralateral leg. Tightly close with the Velcro strap.

Step 2

The straps and anchor kit are adjustable: Remove the Velcro ends and cut the strap to the desired length. Reapply the Velcro ends and tightly close with the Velcro strap to ensure the brace is stable.

Step 3

Pass the collar strap under the collar or harness and attach the other strap under the back strap.

NOTE: Exchanges and returns will NOT be accepted if the brace is altered.

Tips & Tricks

CONTACT US

Maintenance & Repair

A clean brace not only prevents infections, irritation, and a stinky smell; but it also allows your brace to last longer. To help support the longevity of your bracing device, here are some of our tips on how to properly clean your orthopedic bracing:

1. Remove as much hair as possible from any Velcro^® frequently to prevent compaction.
2. Use lint roller or lightly adhesive tape to remove hair from the material of the brace.
3. By hand, use warm water and a gentle cleansing soap to remove any stains and odors.
4. Rinse soap thoroughly from the brace
5. Hang to dry. Once the brace is completely dry, it is ready for use!
